Users Guide ValueJet 1614
44 AP-75790 Rev 1.4 -22/02/2011,
4.3 HANDLING AND INSTALLING MEDIA
Notes
Refer to General info on usable media for details on media handling.
It is recommended to use tested and compatible media for this printer.
Refer to the following topics for types and details of media:
± General info on usable media
4.3.1 Installing roll media
Notes
There are two optional winding systems available for the ValueJet 1614
± Unwinder/Winder 100
± Motorized winding system with tensioning (T winder)
Please refer to the User Guide of the chosen system to know how to correctly load media
Refer to the pricing sheet for more details of these systems.
If you do not use one of the above winding systems. You have to use the scroller which is supplied with
the printer.
For media with a three inch core, three inch core adapters have to be used.
Notes
Set the roll media on a flat and levelled surface.
If the roll media and scroller are placed in a vertical position, the scroller might get damaged.
Notes
The following roll media can be attached to the scroller supplied with this unit.
± Media tube diameter: three inches, outside diameter of media: 150mm or less, weight: 30kg or less.
Be sure to read and understand the safety warnings before handling the printer.
To Next Page
