MUTOH valuejet 1614 - Nozzle Check; Mode Print

Users Guide ValueJet 1614
63 AP-75790  Rev 1.4 -22/02/2011,
4.4.3 Nozzle check
Used to check whether there are any head clogging, missing nozzles or misfiring nozzles.
Notes
If the nozzle check result indicates that the checked points are blurred or missing, clean the head.
Refer to: Head cleaning.
Perform the nozzle check once again after the head has been cleaned.
Notes
For the printing procedure, refer to Performing a test print.
4.4.4 Mode Print
Used to confirm the following printing conditions:
Print mode
Effect
Pre heater set temperature
Fixer (Platen) heater set temperature
Drier heater set temperature
Adjustment value
Notes
For the printing procedure, refer to Performing a test print.
