VJ-1624/1624W OPERATION MANUAL 4 Handling the printer
4-37
11. Remove the whilte reference plate from the plate installation place, turn it over so that the white side
faces up, and install it back to the original place.
NOTE
• Before measuring the color target, make sure that the whilte side of the whilte reference plate
is facing up.
If the black side is facing up, it will not be measured accurately.
12. Close Maintenance cover.
• Print head moves to the right.
• "Wait for a while..." is displayed on Operation panel.
No. Name
1 Whilte reference plate
2 Plate installation place
No. Name
1 Maintenance cover
1
1
2
2
3
1
To Next Page
