VJ-1624/1624W OPERATION MANUAL 6 Maintenance
6-37
5. Use Cleaning stick to remove the ink and dust on Cleaning wiper.
a. Front side of Cleaning wiper:
Remove the ink and dust in the horizontal direction.
b. Cleaning wiper back side:
Remove the ink and dust in the upper direction.
No. Name
1 Cleaning wiper
2 Cleaning stick
3 Head cap unit
No. Name
1 Cleaning wiper
2 Cleaning stick
3 Head cap unit
1
2
3
3
3
1
3
2
To Next Page
