3 Before using VJ-1624/1624W OPERATION MANUAL
3-18
6. Insert Cleaning cartridge into Ink cartridge slot.
• Keep the arrow of Cleaning cartridge facing up and insert it into the printer.
• Insert Cleaning cartridge all the way in Ink cartridge slot.
• If the head height is set to High, "Change Head Gap Low" is displayed on Operation panel.
Change the head height to Low.
4.2.5 Head height adjustment
• When all Cleaning cartridges are installed, "Busy-Washing" is displayed on Operation panel, and
the printer starts charging the cleaning fluid.
• When Cleaning fluid has been charged, "Remove Cartridges" is displayed on Operation panel.
No. Name
1 Cleaning cartridge
2 Arrow
No. Name
1 Cleaning cartridge
2 Ink cartridge slots
2
1
1
2
To Next Page
