VJ-1624/1624W OPERATION MANUAL 3 Before using
3-55
c. Make sure that the protruding portion of Damper stopper is in the groove of Damper drive
switching plate.
d. If it is not in the groove, hold Damper drive switching plate and rotate Damper stopper, and then
put the protruding portion in Damper drive switching plate.
No. Name
1 Protruding portion of Damper stopper
2 Groove of Damper drive switching plate
No. Name
1 Damper drive switching plate
2 Damper stopper
2
1
2
NGOK
1
2
1
