VJ-1624/1624W OPERATION MANUAL 3 Before using
3-57
2. Pull out Damper lugs of Roll media holders L and R on the back of the printer, and rotate it by 90
degrees.
• Rotate Damper lugs by 90 degrees until they click and fit. Every time Damper lugs rotate by 90
degrees, the torque setting switches between 1kg and 4kg.
• Switch the torque settings for both Roll media holders.
• The torque is set at either 1kg or 4kg as shown below.
No. Name
1Media
2 Roll media holder
3Damper lug
No. Name
1Damper lug
12 2
1
2
3
3
2
1
1
1
4kg
1kg
