Operator's Manual
An operator’s manual is available for the MY500 JetPrintert machines.
This manual is provided with each machine.
The operator’s manual is available in the same languages as the JPSys
software.
The operator’s manual contains information to assist the operator to start and
operate the system, load components and handle magazines and trays.
Information about safety, daily maintenance is also included in the operator's
manual.
Programming Manual
A programming manual is available for JPI version 1.5.
This manual is provided with each machine.
The programming manual is available in English only.
The programming manual contains basic information about the creation of
MY500 machine programs. Board information, such as package footprints,
will be matched to preferred settings to generate solder paste patterns. This
will result in movement instructions for the machine.
MYCamJP
A manual for MYCam JP is provided with each mnachine.
The MYCam JP manual is available in English only.
MYCam JP is used for the importing and processing of basic CAD data needed
for programming in JPI. MYCam JP can handle various CAD-file formats and
use graphics for this process.
