MYDATA MY500 JetPrinter - Electrical Connection; Power Plug Connection

MYDATA MY500 JetPrinter Installation
P-030-0014-EN – Service Manual Rev. 0003 2008-06 2 - 15
Electrical Connection
This machine is intended to be stationary and movable to accommodate the
changing production needs of the end use factory (this is in compliance with
the NEC Article 400-7 and -8).
Power Plug Connection
The machine mains transformer is connected by the mains power cord shown
in Figure 2-10.
Connect the cable to the mains power. Available plug types are shown in
Figure 2-11 and 2-12.
Figure 2-10. Power plug.
Figure 2-11. Power plug, US. Figure 2-12. Power plug, Europe.
