Electrical Requirements
Always follow the existing local, national or international regulations when
installing this equipment.
Acceptable voltages (±10 %): 230/115 VAC.
Compressed Air
The pneumatic system in the machine requires compressed air. Minimum
pressure required is 7 bar, maximum allowed is 10 bar.
Transporting the Machine
Whenever the machine has to be transported, avoid vibrations and impacts in
order to prevent damage to the machine. It must be ensured that the machine
is stable while it is being transported.
Truck transport
Remove the optional equipment and the MMI-module (i.e. the arm and tube
holding the screen and keyboard) and by-pack it in a separate box.
Secure the Y beam with the transport lock, see page 2-20 for details on the
lock. Fix the X wagon in position secured to the cassette exchange plate using
cable ties, see Figure 2-17. To secure the X wagon do as follows:
– Position the X wagon above the cassette exchange plate.
– Draw the cable ties through the holes in the plate.
– Tighten them around the end stops of the x-wagon. The cable ties
must be tight enough to ensure that the X wagon does not move.
CAUTION! Ensure that the left cable tie does not touch the camera.
To prevent dust and dirt to enter the machine you should wrap it in plastic.
Please refer to page 2-10 for details on how to lift and move the machine.
Use strong straps to secure the machine and equipment to the truck bed. The
machine should be tied down to the truck bed with straps attached to the
machine’s leveling feet.
Air and sea transport
For air and sea transport there is a special crate, and special locking brackets
available from MYDATA.
