Installation MY500 JetPrinter MYDATA
2 - 2 Rev. 0003 2008-06 P-030-0014-EN – Service Manual
Site Preparation
In this section you will find prerequisites of what is required of the site for a
successful installation of a MYDATA MY500 JetPrinter. Details about the
working area, environmental and electrical requirements, and regulatory
compliance are given. Follow these directions to ensure a safe and proper
installation, as well as ongoing operating efficiency.
Site preparation check list
1. Identify the desired location for the machine. Verify that enough space
is available.
2. Verify that all environmental requirements are met, for example:
– Temperature
– Humidity
– Cleanliness/airborne contaminants.
3. Verify that the floor is level and can take the weight.
4. Plan the transportation route to the installation site.
Check that the transportation route can take the weight of the machine.
5. Verify that means for transportation and lifting are available (for
instance fork lift or crane).
6. Obtain required, stable input power.
7. Obtain pneumatic air connection.
8. Arrange for electrostatic avoidance equipment.
9. Table (and chair) for offline station.
10. Network connection.
Required Working Area
Space around the machine is necessary for maintenance of the machine and
optional equipment, if any. Prepare a suitable working area according to the
dimensions shown in Figure 2-1, Figure 2-3 and Figure 2-4. The dimensions
shown are the minimum space required for the machine with no extra options
or external conveyors. To achieve a more efficient working area, add space for
operating personnel and storage area for solder paste and boards.
Machine weight
The floor, on which the machine is transported and finally positioned, must
support the machine weight, which is 2 000 kg net weight.
