Routine Maintenance MY500 JetPrinter MYDATA
5 - 6 Rev. 0003 2008-06 P-030-0014-EN – Service Manual
Filters
The air filter indicator (’A’ in the figure) is located on one of the two air
filters.
If the machine is equipped with an optional Refrigerated Air Dryer unit,
the air filters are located on that unit.
– Replace both the filters if the filter indicator has turned red (refer to
the filter manual).
These filters must be exchanged every two years.
Optional Refrigerated Air Dryer
– Make sure the auto drain operates properly (refer to the Refrigerated
Air Dryer manual).
CAUTION! A bad quality of compressed air can cause auto drain malfunction.
Figure 5-7. Air filter indicator.
A
