Installation MY500 JetPrinter MYDATA
2 - 12 Rev. 0003 2008-06 P-030-0014-EN – Service Manual
Moving and Placing the Machine
Move the machine to the final position and put it on the leveling feet. You can
use either a fork lift or a crane.
CAUTION! Always ensure that the transport lock is attached before moving
the machine. If not the Y wagon may be damaged, see page 2-20.
Leveling
When the machine has been placed in the final location, check the leveling as
described below.
1. Place a spirit level on the machine and adjust the leveling feet until the
machine is level in both directions.
2. Make sure that each leveling foot is screwed firmly against the floor so
that the weight of the machine is divided equally on the four feet.
3. Check if the machine is steady by manually trying to rock the machine.
If not, adjust the leveling feet.
4. Tighten the locking nut on each leveling foot.
