14 Cirrus LT Plus User Manual v1.2 - Chapter 1
Laptop and docking station LED status light indicators
Power LED
Green LED – Normal Operation – unit is powered on
Amber LED – Wake On LAN is enabled/unit is OFF
No LED – unit is off (Wake on LAN is disabled)
Blinking Green LED – Host PC is in low power (sleep state)
Blinking Green and Amber - unit is in the process of upgrading BIOS (DO NOT
TURN OFF)
Battery LED
Green LED – Battery is full or AC adapter is plugged IN
Blinking Green LED – Battery is charging
Blinking Amber LED - Low Battery, Battery is under 10% charge, or battery is
not present
Amber LED – charging error
NO LED – normal operation, battery discharging
Wireless LED
Green LED – Wireless is enabled/ this can be on when not connected to a
wireless LAN.
NO LED – Wireless is disabled
PCoIP LED
Green LED – Connected to a remote host
NO LED – no connection present
Caps Lock LED
Green LED – CAPS LOCK Enabled
NO LED – CAPS LOCK Disabled
NumLock LED
Green LED – NumLock Enabled
NO LED – NumLock Disabled
