156 Cirrus LT Plus User Manual v1.2
Appendix: Specifications
Processor Teradici PCoIP Processor Tera2321
Storage N/A - No local storage
Memory 512MB DDR3
Display 15.6” FHD 16:9 LCD, 1920x1080 with Anti-Glare, LED-Backlight
Imaging Performance
50Mpps (VDI)
130Mpps (Workstation)*
Audio Integrated Realtek high definition audio subsystem with 2x 1.5W built-in speakers
Networking
Integrated Realtek 10/11/1000Mb Base-TX Ethernet LAN
Optional Ralink 802.11 A/b/g/n 3T3R 450Mbps wireless LAN
Optional Sierra wireless 4G LTE, 3G, 2G cellular wireless LAN
Wake on LAN support
Integrated Webcam 2.0 mega pixel webcam with integrated mic (optional)
I/O Ports
1x USB mouse port, 1x USB keyboard port, 2x USB Tera2 ports, optional
smart card reader or optional proximity reader, 1x mic-in, 1x mini Display-
Port, 1x headset jack, 1x RJ-45 port, 1x DC-in, 1x USB charging port**
Internal Expansion Slots
1x mini card slot for WLAN options (supports half and full size cards)
1x mini card slot for 4G cellular (supports half and full size cards)
Battery
Primary external 6-cell Li-ion smart battery (5,200 mAH)
Secondary internal 6-Cell Li-ion smart battery (6830 mAH)
Over 8 continuous hours of usable battery power with typical usage
Keyboard & Pointing Device
99-key chiclet style keyboard
Touchpad pointing device
Support for external USB keyboards with multi-functions (driver loaded on host)
AC Adapter Output: 19V DC, Input: 100~240V AC, 50/60Hz universal, 3.42A, auto-sensing
Security
Kensington lock
Optional fingerprint reader: either Swipe or FIPS 201 Touch
TPM 1.2 (in the future)
Secure boot (future Firmware support required)
1x smart card reader or optional proximity reader
Dimensions
(L x W x H) & Weight
15.16” x 10” x 1.26”/ 385mm x 254mm x 32mm;
4lbs / 1.8 Kg (without battery)
4.71 lbs / 2.14 Kg (with primary battery)
5.5 lbs / 2.49 Kg (with both batteries)
Environmental
Operating temp: 0° to 35° c (32° to 95° f ) @ 5-95% relative humidity
Storage temp: -20° to 60° C (-4° to 140° F) @ 5-95% relative humidity
Docking Station
(lockable with a key)
1x DC-in, 1x Line-out jack, 1x microphone jack, 1x USB mouse port, 1x USB keyboard
port, 2x PCoIP USB ports, 1x fiber SFP port, 1x RJ-45 port, and 1x charging USB port**
Regulatory &
Product Certifications
EMI/RFI: FCC ClassB
Safety: UL 60950, UL 2054, UN 38.3, CE
Other: TAA
*Workstation: when used in conjunction with PCoIP hardware host solution
**Charging port is NOT a high current port.
Note: Specifications are subject to change without notice.
