Example of LINE Cable and MDF Cross Connection for CCH
42 TXT 17 TXR
43 RCV T 18 RCV R
44 19
45 20
17 TXR 42 TXT
18 RCV R 43 RCV T
19 44
20 45
PIM0
JP
MDF
CCH
AP05
[LT05]
LTC1
MODULAR
19
44
20
45
44
20
45
19
TX R
TX T
RCV R
RCV T
17
42
18
43
42
18
43
17
DTE
LINE
MODEM
LTC (J) (P)
TERMINAL
(TX Ring)
(TX Tip)
(RCV Ring)
(RCV Tip)
Not Used
