Service Conditions for Centralized Billing
If all the PBXs within the network are the 2000 IPS, the PBX can be a center billing office. In this case,
there are the following conditions:
Conditions for Center Office;
- The available combination between SMDR and the output format is as follows. One type of SMDR is
available among the following SMDR in center office.
NOTE: The extended NEAX 2400 IMS format is available by using SC-3168 MRCA program issue 2 or
later.
- When the center office supports extended NEAX 2400 IMS format, the billing information received
from each local office can be output with either extended NEAX 2400 IMS format or former
NEAX 2400 IMS format. When the center office does not support extended NEAX 2400 IMS format
(Series 3300 or earlier), the billing information from each local office can output with only former
NEAX 2400 IMS format.
- Maximum of eight local offices can be accommodated.
- Maximum of 3600 calls per hour can be received from local office. If exceeds 3600 calls per hour, the
billing information is stored in the local office.
SMDR
Former NEAX 2400 IMS
format
Extended NEAX 2400 IMS
format
SMDR with AP00
(PN-AP00-B with AP00
program)
Available Not Available
SMDR with AP00
(PN-AP00-B/PN-AP00-D
with MRCA program)
Available Available
[Series 3400 software or later]
NOTE
MP built-in SMDR on
RS-232C
Not Available Not Available
MP built-in SMDR on IP Available
[Series 3400 software or later]
Available
[Series 3400 software or later]
