CHAPTER 2 INSTALLATION
ā 63 ā NWA-008853-001 Rev.3.0
97ch2001.fm
This table shows the equipment and cables required when providing No. 7 CCIS with analog interface.
Required Equipment for Analog CCIS
* Should be provided with customer.
EQUIPMENT DESCRIPTION QUANTITY REMARKS
PN-2LDT (LDT) or
PN-4LDT (LDT) or
PN-2ODT (ODT)
Loop Dial Trunk or
2-wire E&M/4-wire E&M Trunk
1-128 (2LDT/ODT)
1-64 (4LDT)
PN-SC00 (CCH) Common Channel Handler Card 1-8
PN-AP00-B
(AP00)
Application Processor Card for
Centralized Billing
1 For center office
PN-AP00-D
(AP00)
Application Processor Card for
Centralized Billing
1 For center office
PZ-M537
(EXPMEM)
Expansion Memory Card for
AP00
1 For Call Record
expansion
Page 19
MODEM* For Common Signaling Channel N N: Number of CCH
RS NORM-4 CA-A/
RS NORM-4S CA-A
Connecting cables between CCH
and MODEM
N N: Number of CCH
Length: 4 m (13.1 ft.)
LINE Cable* Connecting cable between
MODEMs
N N: Number of CCH
JULY/01/2006
REQUIRED EQUIPMENT
