REQUIRED EQUIPMENT
This table shows the equipment required when providing No. 7 CCIS with digital interface to the system.
Required Equipment for Digital CCIS
NOTE: When the CCT card is used, the CCH card is not required.
Continued on next page
EQUIPMENT DESCRIPTION QUANTITY REMARKS
PN-24DTA-C
(24DTI)
24-channel DTI Card 1-8
PN-30DTC-C
(30DTI)
30-channel DTI Card 1-8
PZ-M542/
PZ-M557
(CONN)
Connection Card for Coaxial
Cable
As required 1 DTI/card, 1 CCT/
card
Maximum 2 cards/
PIM
PN-M10
(M10)
Optical Fiber Interface Card As required 2 DTIs/card
2 CCTs/card
PN-SC00
(CCH)
Common Channel Handler Card 1-8 1 card/DTI NOTE
PN-24CCTA
(24CCT)
24-channel CCT Card 1-8
PN-30CCTA
(30CCT)
30-channel CCT Card 1-8
PN-DTA
(24/30CCT)
24/30-channel CCT Card 1-8
PN-AP00-B
(AP00)
Application Processor Card for
Centralized Billing
1 For center office
