CHAPTER 3 SYSTEM DATA PROGRAMMING
– 105 – NWA-008853-001 Rev.3.0
97ch3001.fm
Numbering Plan Assignment
• For open numbering system
DESCRIPTION DATA
Assign the access code for LCR Group 0-3. •
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code
A126: LCR Group 0
A127: LCR Group 1
A128: LCR Group 2
A129: LCR Group 3
Assign an Area Code Development Pattern
number to each LCR Group.
•
(1)
(2)
Y=A000
0-3: LCR Group 0-3
4005-4007: Area Code Development pat-
tern No. 5-7
Assign a Route Pattern number to the digits to
be dialed in the Area Code Development Pat-
tern number assigned by CM8A Y=A000.
•
(1)
(2)
Y=4005-4007 Area Code Development
Pattern No. 5-7
X-X---X: Area Code 1-8 digits
0000-0255: Route Pattern No. 000-255
Assign an area code for intra-office termina-
tion, if required.
•
(1)
(2)
Y=4005-4007 Area Code Development
Pattern No. 5-7
X-X---X: Area Code 1-8 digits
8000: Intra-Office Termination
Assign the next Route Pattern number to the
Route Pattern number assigned CM8A
Y=4005-4007.
NOTE: This data is required to expand the
order of LCR selection that is as-
signed by CM8A Y=0000-0255.
The order of LCR selection can be
expand to the maximum seventh.
•
(1)
(2)
Y=0000-0255 Route Pattern No. 000-255
0: Designation of next table
0000-0255: Next Route Pattern No. 000-
255
Specify the order LCR selection for the Route
Pattern number assigned by CM8A Y=4005-
4007.
•
(1)
(2)
Y=0000-0255
Route Pattern No. 000-255
1: 1st
2: 2nd
3: 3rd
4: 4th
XXX ZZ
XXX: 000-255: LCR Pattern No.
ZZ : 00-63: Trunk Route No.
START
CM20
CM8A
A
DIGITAL CCIS PROGRAMMING
