PN-2LDTA (LDT)
Locations of Lamps, Switches, and Connectors
Lamp Indications
Switch Settings
This card has no switches.
LAMP
NAME
COLOR FUNCTION
BL0, 1 Red • Remains lit when the corresponding circuit is in use.
• Flashes at 60 IPM when the corresponding circuit is in make-busy
state or the system data for this card is not assigned.
BL1
BL0
PN-2LDTA (LDT)
