CHAPTER 2 INSTALLATION
ā 66 ā NWA-008853-001 Rev.3.0
97ch2001.fm
Mounting CCH Card
(1) Before mounting the CCH (PN-SC00) card, set the MB switch to UP position,
and set the other switches to appropriate position.
See CHAPTER 4. Page 401
(2) Mount the CCH card in the following AP slots of PIM0 through PIM7.
PIM0-7: AP00-AP11 slots
PIM0 (for Backup CPU): AP00-AP10 slots
(3) After mounting the card, set the MB switch to DOWN position to put the card in service.
ATTENTION
Contents
Static Sensitive
Handling
Precautions Required
INSTALLATION PROCEDURE FOR DIGITAL CCIS
