CHAPTER 2 INSTALLATION
– 74 – NWA-008853-001 Rev.3.0
97ch2001.fm
Selection of PLO in MP Card
(1) Select the PLO input by the switch settings of MP (PN-CP24-A/PN-CP24-B/
PN-CP24-C/PN-CP24-D/PN-CP27-A/PN-CP27-B) card as follows.
• Selection of PLO0 input
For clock receiver office:
For clock source office:
SW2-2 SW2-3
OFF OFF
• Selection of PLO1 input
For clock receiver office:
For clock source office:
SW4-3 SW4-4
OFF OFF
(2) Mount the MP card in the MP slot of PIM0.
SW2-2 SW2-3 FUNCTION
OFF OFF 1.5 MHz clock
[For PN-24DTA/PN-24CCT/PN-DTA/PN-
24PRT/PZ-M649]
ON OFF 192 kHz clock
[For PN-BRTA]
OFF ON 2 MHz clock
[For PN-30DTC/PN-DTA/PN-2BRT/PN-
4BRT/PN-30CCT/PN-30PRT/PZ-M650]
ON ON Not used
SW4-3 SW4-4 FUNCTION
OFF OFF 1.5 MHz clock
[For PN-24DTA/PN-24CCT/PN-DTA/PN-
24PRT/PZ-M649]
ON OFF 192 kHz clock
[For PN-BRTA]
OFF ON 2 MHz clock
[For PN-30DTC/PN-DTA/PN-2BRT/PN-
4BRT/PN-30CCT/PN-30PRT/PZ-M650]
ON ON Not used
ATTENTION
Contents
Static Sensitive
Handling
Precautions Required
JULY/01/2006
INSTALLATION PROCEDURE FOR DIGITAL CCIS
