CHAPTER 3 SYSTEM DATA PROGRAMMING
– 129 – NWA-008853-001 Rev.3.0
97ch3001.fm
LDT/ODT Assignment
DESCRIPTION DATA
Assign a trunk number to each LDT/ODT
card.
NOTE 1: We recommend the setting of trunk
number by CM14, when using Series
3200 R6.2 software or later.
NOTE 2: The Trunk number must be assigned
to the 1st LEN (Level 0) and the 2nd
LEN (Level 1) of each LT slot.
(1)
(2)
000-763: LEN
D000-D254: Trunk No.
Any trunk number already assigned by
CM07 cannot be used.
Do not assign Trunk No.D255 for CCIS.
Assign a trunk number to each LDT/ODT
card.
[Series 3200 R6.2 software required]
NOTE: The Trunk number must be assigned
to the 1st LEN (Level 0) and the 2nd
LEN (Level 1) of each LT slot.
(1)
(2)
XX ZZZ (LEN)
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
DD000-DD254: Trunk No.
NONE : No data
Any trunk number already assigned by
CM07 cannot be used.
Do not assign Trunk No.255 for CCIS.
Assign a trunk route number to each trunk. •
(1)
(2)
Y=00
000-254: Trunk No. assigned by CM10/
CM14
00-63: Trunk Route No.
START
CM10
CM14
CM30
A
ANALOG CCIS PROGRAMMING
To Next Page
