CHAPTER 3 SYSTEM DATA PROGRAMMING
– 130 – NWA-008853-001 Rev.3.0
97ch3001.fm
DESCRIPTION DATA
Assign the trunk route data for voice channels. •
(1)
(2)
Y=00
00-63: Trunk Route No.
04: Tie Line
•
(1)
(2)
Y=01
00-63: Trunk Route No.
7: DP/DTMF
•
(1)
(2)
Y=04
00-63: Trunk Route No.
2: Answer Signal arrives
•
(1)
(2)
Y=05
00-63: Trunk Route No.
1 : Release Signal arrives
•
(1)
(2)
Y=09
00-63: Trunk Route No.
03: Wink Start/CCIS
•
(1)
(2)
Y=20
00-63: Trunk Route No.
00: Wink Start/CCIS
When you use the ODT card for 2-wire E&M
trunk, set CM35 Y=100 to 14.
•
(1)
(2)
Y=100
00-63: Trunk Route No.
14: 2-wire E&M Trunk
NOTE: When using Series 3600 software or later, a reset of the MP card is not required after this
command is set/changed.
When changing the data with online, the data is valid after the trunk card is unplugged and
plugged in.
If the echo occurs when you use the LDT card,
set CM35 Y=100 to 07.
(1)
(2)
00-63: Trunk Route No.
07: LDT (for short line only)
A
CM35
INITIAL
INITIAL
B
JANUARY/31/2006
ANALOG CCIS PROGRAMMING
To Next Page
