CHAPTER 3 SYSTEM DATA PROGRAMMING
– 280 – NWA-008853-001 Rev.3.0
97ch3004.fm
HOUSE PHONE-CCIS
General Description
This feature allows selected stations to call an Attendant Console, through the CCIS network, simply by
going off hook.
Programming
Use the Hot Line-Outside feature.
DESCRIPTION DATA
Assign a Hot Line (House-phone) to the re-
quired station.
•
(1)
(2)
Y=03
X-XXXXXXXX: Station No.
04: Hot Line (House-phone)
Allocate memory area for Hot Line-Outside
calls. For example, to assign 10 Hot Line-Out-
side calls into No. 100 through No. 109 Mem-
ory Slots, 2nd data is “100010.” Abbreviated
Codes are automatically assigned as shown be-
low:
(1)
(2)
65: For Hot Line-Outside
XXX ZZZ
XXX: 000-299 (Starting Memory Slot No.
in blocks)
ZZZ : 001-300 (No. of Memory Slots to be
assigned in blocks)
Assign the destination party’s number to each
Memory Slot number.
•
(1)
(2)
Y=0
000-299: Memory Slot No.
XXXX YY...Y
XXXX : Access Code (Maximum 4 digits)
: Separator Mark
YY...Y : Calling Party’s No.
(Maximum 26 digits)
Define the Hot Line (House-phone) pairs. •
(1)
(2)
Y=00-99 Hot Line Pair No.
0: Calling Side
X-XXXXXXXX: Virtual Station No.
(1)
(2)
1: Called Side
C XX (for Outside party)
XX: 00-09 (Abbreviated Code given by
CM71)
START
CM12
CM71
Memory Slot 100
Memory Slot 109
~
Abbrev. Codes
00
09
~
CM72
,
,
CM52
END
HOUSE PHONE-CCIS
To Next Page
