– 362 – NWA-008853-001 Rev.3.0
97ch4001.fm
PN-AP00-D (AP00)
Locations of Lamps, Switches, and Connectors
RS3
RS2
RS1
RS0
SENSE
RUN
MB
SW0 SW2
L3
L2
L1
L0
SW1
JP0
JP1
JULY/01/2006
PN-AP00-D (AP00)
