DESCRIPTION DATA
Specify the PAD Patterns on the voice channel
route.
[Australia/New Zealand]
•
(1)
(2)
Y=19
00-63: Trunk Route No.
0-3 : Programmable PAD
(See CM42 Page 133)
4-7 : Fixed PAD
(See left column.)
B
CM35
T/R: Transmit/Receive
+: Gain
–: Loss
CONNECTION
PATTERNS (A-B)
PAD DATA OF B TRUNK [dB]
DATA
=4 (T/R)
DATA
=5 (T/R)
DATA
=6 (T/R)
DATA
=7 (T/R)
Station-ODT 0/0 0/0 0/0
Tone-ODT 0/0 0/0 0/0
COT/DID/LDT/
IPT-ODT
0/0 –8/–8 –8/–8
ODT-ODT 0/0 –8/–8 –3/–3
DTI/BRT/PRT/
CCT/Virtual IPT-
ODT
0/0 –8/–8 –3/–3
Station-LDT 0/+6 0/+6 0/+6
Tone-LDT 0/+6 0/+6 0/+6
COT/DID/LDT/
IPT-LDT
0/+6 –6/+6 –6/+6
ODT-LDT 0/+6 –6/+6 0/+6
DTI/BRT/PRT/
CCT/Virtual IPT-
LDT
0/+6 –6/+6 0/+6
C
ANALOG CCIS PROGRAMMING
