CHAPTER 1 GENERAL INFORMATION
– 13 – NWA-008853-001 Rev.3.0
97ch1001.fm
- The billing information of own office (center office) and the billing information from local office/tan-
dem office can be stored as follows.
NOTE: When the memory of the MP overflows, new billing information is cancelled. The call records
will be cleared by the power off or system reset.
- If the billing information is not sent to the SMDR terminal due to such as a failure of the SMDR
terminal, the billing information is stored in center office. Moreover, if the memory is filled, the billing
information is stored in the local office.
- The maximum number of SMDR terminal that can be connected is as follows.
SMDR with AP00 (PN-AP00-B with AP00 program) : 2
SMDR with AP00 (PN-AP00-B/PN-AP00-D with MRCA program): 2
MP built-in SMDR on IP : 1
SMDR Center Office Local/Tandem Office
SMDR with AP00
(PN-AP00-B with AP00
program)
800 calls
(without expansion memory)
27000 calls
(with expansion memory)
512 calls
SMDR with AP00
(PN-AP00-B with MRCA
program)
1310 calls
(without expansion memory)
22270 calls
(with expansion memory)
512 calls
SMDR with AP00
(PN-AP00-D with MRCA
program)
22270 calls 512 calls
MP built-in SMDR on IP 1024 calls NOTE Not stored
JULY/01/2006
SYSTEM OUTLINE
