CHAPTER 3 SYSTEM DATA PROGRAMMING
– 120 – NWA-008853-001 Rev.3.0
97ch3001.fm
For office A, the following programming is required:
(1) Assign the DTI card.
(2) Assign a trunk number to the required DTI channels.
(3) Assign the DTI card parameters.
(These data assignments are only for 24DTI card.)
(4) Assign a trunk route number to the DTI trunks.
Command Code 1st Data 2nd Data
05 Y=0 04 09 : DTI0
05 09 : DTI1
05 Y=1 04 1 : Basic Highway channel
05 1 : Basic Highway channel
Command Code 1st Data 2nd Data
07 Y=01 0401 D000 : TRK000
0402 D001 : TRK001
0403 D002 : TRK002 (Common Signaling Channel)
0501 D003 : TRK003
0502 D004 : TRK004
0503 D005 : TRK005 (Common Signaling Channel)
Command Code 1st Data 2nd Data
AA Y=00 04 0
05 0
AA Y=01 04 0/1
05 0/1
AA Y=02 04 0/1
05 0/1
AA Y=03 04 7
05 7
Command Code 1st Data 2nd Data
30 Y=00 000 10
: RT10
001 10
002 11 : RT11
003 12
: RT12
004 12
005 13 : RT13
DIGITAL CCIS PROGRAMMING
