CHAPTER 3 SYSTEM DATA PROGRAMMING
– 193 – NWA-008853-001 Rev.3.0
97ch3003.fm
DESCRIPTION DATA
Clear the billing memory. (1)
(2)
0000
CCC
On the AP00 card, set the SW1 switch as
shown below:
SW1-4 should be set as follows;
ON : The AP No. is 04-15
OFF: The AP No. is 20-31
NOTE 1: “DATA ERROR” will be indicated when CMD102>000: CCC is entered in case that the
sum of all call records numbers set by second data of CMD003>23, 24, 25, 26, 28, 29, 30
exceeds the amount of call records number shown in NOTE 2 below, or System Data All
Clear by CMD101 is not executed.
NOTE 2: By entering the 1st data “0000”, status of the EXPMEM card (PZ-M537) will be displayed
as shown below.
B
CMD102
AP OFF LINE
SW1
ON
: POSITION TO BE SET
4
3
2
1
No EXPMEM on AP00 is provided EXPMEM on AP00 is provided
When CMD001>179
is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
When CMD001>179
is set to 1
(Center Office of
Centralized Billing-
CCIS)
When CMD001>179
is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
When CMD001>179
is set to 1
(Center Office of
Centralized Billing-
CCIS)
1600 800 27000: When CMD003>28 is set to 0
(Call Record for CIS is not provided)
26000: When CMD003>28 is set to other than 0
(Call Record for CIS is provided)
C
CENTRALIZED BILLING-CCIS
