Example 2: Data Assignment of SMDR Call Record on a Tandem Call through CCIS
To provide one SMDR call record showing the office number and the station that made the call in Office A.
Data Assignment of Office B
CM08>040: 0 (Provides SMDR service for tandem calls)
CM08>377: 0 (Provides office number and station number from the tandem office)
CM35 Y=14>C.O. Route No.: 1 (To provide)
CMDD00>2: 1 (To send)
Data Assignment of Office A
CM35 Y=14>CCIS Route No.: 0 (Not provided)
CMA7 Y=06>CCH No.:0000-9999 (Originating Office Number)
Data Assignment of Office A
ARTD CDN 10>CCIS Route No.: 0
C.O.
SMDR Terminal
Office A
2000 IPS/2400 IPX
Office B
2000 IPS
CCIS
CENTRALIZED BILLING-CCIS
To Next Page
