CHAPTER 3 SYSTEM DATA PROGRAMMING
ā 289 ā NWA-008853-001 Rev.3.0
97ch3004.fm
Hardware Required
DK card Ć 1/External Equipment Interface on the MP card
External Indicator (Bell, Lamp etc.)
provided by the customer
For the cross connection of External Indicator, refer to Installation Procedure Manual.
Operating Procedure
No manual operation is required.
DESCRIPTION DATA
Assign the function of CCIS Link Alarm Indi-
cation to the DK.
(1)
(2)
XX Y
XX : 00-31 (Card No. assigned by CM10/
CM14>E800-E831)
Y : 0-3 (Circuit No.)
313 : Built-in External Equipment Interface
on MP card
35 XX
XX: 01-07 (CCIS CH No.)
A
CM44
END
LINK ALARM DISPLAY-CCIS
To Next Page
