Programming
DESCRIPTION DATA
Assign a network station number to the re-
quired LEN.
NOTE: We recommend the setting of net-
work station number by CM14,
when using Series 3200 R6.2 soft-
ware or later.
(1)
(2)
000-763: LEN
X-XXXXXXXX: Network station No.
Assign a network station number to the re-
quired LEN.
[Series 3200 R6.2 software required]
(1)
(2)
XX ZZZ (LEN)
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
X-XXXXXXXX: Network station No.
NONE : No data
Assign the Access Code for the number of dig-
its of the network station number.
•
(1)
(2)
Y=0-3: Numbering Plan Group 0-3
X-XXXX: Access Code
811-818: 1-8 digits network station No.
Assign the Area Code Development Pattern
number for LCR Group.
•
(1)
(2)
Y=A000
0-3: LCR Group No. 0-3
4005-4007: Area Code Development Pat-
tern No. 5-7
Assign the Route Pattern number to each area
code for the Area Code Development Pattern
number assigned by CM8A Y=A000.
•
(1)
(2)
Y=4005-4007: Area Code Development
Pattern No. 5-7
X-XXXXXXXX: Area Code
0000-0255: Route Pattern No. 000-255
Assign the next Route Pattern number to the
Route Pattern number assigned by CM8A
Y=4005-4007.
NOTE: This data is required to expand the
order of LCR selection that is as-
signed by CM8A Y=0000-0255.
The order of LCR selection can be
expand to the maximum seventh.
•
(1)
(2)
Y=0000-0255 Route Pattern No.000-255
0: Designation of next table
0000-0255: Next Route Pattern No.000-
255
START
CM10
CM14
CM20
CM8A
A
NETWORK STATION NUMBER-CCIS (FCCS)
