• For Satellite Office
Operating Procedure
1. Lift the handset and receive dial tone.
2. Dial the Single-Digit preprogrammed station number.
3. The called station will be rung.
DESCRIPTION DATA
Assign the single-digit station number to LCR
Group 3 (A129).
•
(1)
(2)
Y=0-3 Number Plan Group 0-3
X-XXXX: Access Code
A129: LCR Group 3
Assign an area code table to be used to select a
route pattern table.
•
(1)
(2)
Y=A000
3
4005-4007: Area Code Development Pat-
tern No. 5-7
Assign the same digit which was assigned as
the access code (in CM20) into the selected
area code table.
•
(1)
(2)
Y=4005-4007
X-XXXX: Access Code
0000-0255: Route Pattern No. 000-255
Assign the next Route Pattern number to the
Route Pattern number assigned CM8A
Y=4005-4007.
NOTE: This data is required to expand the
order of LCR selection that is as-
signed by CM8A Y=0000-0255.
The order of LCR selection can be
expand to the maximum seventh.
•
(1)
(2)
Y=0000-0255 Route Pattern No. 000-255
0: Designation of next table
0000-0255: Next Route Pattern No. 000-
255
Assign the route pattern table with the desired
properties and selection of appropriate routes.
•
(1)
(2)
Y=0000-0255
1-4: Order of LCR Selection
1: 1st
2: 2nd
3: 3rd
4: 4th
XXX ZZ
XXX: 000-255 (LCR Pattern No.)
ZZ : 00-63 (Trunk Route No.)
START
CM20
CM8A
END
SINGLE-DIGIT STATION CALLING-CCIS
