CHAPTER 3 SYSTEM DATA PROGRAMMING
– 336 – NWA-008853-001 Rev.3.0
97ch3005.fm
DESCRIPTION DATA
To add the Tenant Pattern:
STEP 1
Assign the area code to be restrict-
ed and the Tenant Pattern number
to the Area Code Development
Pattern number assigned by CM35
Y=76.
•
(1)
(2)
Y=4000-4004
Area Code Development Pattern No.
X-X...X: Area Code (Maximum 8 digits)
1000-1015: Tenant Pattern No. 00-15
STEP 2
Assign the Tenant number and the
Route Pattern number to Tenant
Pattern number assigned by Step 1.
•
(1)
(2)
Y=1000-1015 Tenant Pattern No. 00-15
00-63: Tenant No. 00-63
0000-0255: Route Pattern No. 000-255
STEP 3
Assign the TR Pattern number to
Route Pattern number assigned by
Step 2.
•
(1)
(2)
Y=0000-0255
Route Pattern No. 000-255
1
XXX 00 (TR Pattern No.)
XXX: 000-255: TR Pattern No.
STEP 4
Assign the Toll Restriction Pattern
number assigned by CM81 to TR
Pattern number assigned by Step 3.
•
(1)
(2)
Y=5000-5255 TR Pattern No.
000
00-15 : Toll Restriction Pattern No. 0-15
To add the Time and Date Pattern:
STEP 1
Assign the area code to be restrict-
ed and the Date Pattern number to
the Area Code Development Pat-
tern number assigned by CM35
Y=76.
•
(1)
(2)
Y=4000-4004
X-X...X: Area Code (Maximum 8 digits)
3000-3003: Date Pattern No. 0-3
STEP 2
Assign a date to be applied to Toll
Restriction and Time Pattern num-
ber 0-7 to the Date Pattern number
assigned by Step 1.
Set the data for all dates, one by
one, to be applied Toll Restriction.
•
(1)
(2)
Y=3000-3003 Date Pattern No. 0-3
0-6 (Date)
0: Sunday
1: Monday
2: Tuesday
3: Wednesday
4: Thursday
5: Friday
6: Saturday
2000-2007: Time Pattern No. 0-7
C
CM8A
D
TRUNK-TO-TRUNK RESTRICTION-CCIS
