CHAPTER 3 SYSTEM DATA PROGRAMMING
– 339 – NWA-008853-001 Rev.3.0
97ch3005.fm
NOTE: If no data is set, the initial setting is shown below.
(1) 2000 IPS to 2400 IPX
(2) 2400 IPX to 2000 IPS
Operating Procedure
No manual operation is required.
1ST DATA 2ND DATA
20: 2000 IPS TRK Restriction Class 1
(RCA)
21: 2000 IPS TRK Restriction Class 2
(RCB)
22: 2000 IPS TRK Restriction Class 3
(RCC)
23: 2000 IPS TRK Restriction Class 4
(RCD)
24: 2000 IPS TRK Restriction Class 5
(RCE)
25: 2000 IPS TRK Restriction Class 6
(RCF)
26: 2000 IPS TRK Restriction Class 7
(RCG)
27: 2000 IPS TRK Restriction Class 8
(RCH)
01: 2400 IPX TRK Restriction Class 1
02: 2400 IPX TRK Restriction Class 2
03: 2400 IPX TRK Restriction Class 3
04: 2400 IPX TRK Restriction Class 4
05: 2400 IPX TRK Restriction Class 5
06: 2400 IPX TRK Restriction Class 6
07: 2400 IPX TRK Restriction Class 7
08: 2400 IPX TRK Restriction Class 8
1ST DATA 2ND DATA
30 : 2400 IPX TRK Restriction
Class 0
31 : 2400 IPX TRK Restriction
Class 1
32 : 2400 IPX TRK Restriction
Class 2
33 : 2400 IPX TRK Restriction
Class 3
34 : 2400 IPX TRK Restriction
Class 4
35 : 2400 IPX TRK Restriction
Class 5
36 : 2400 IPX TRK Restriction
Class 6
37 : 2400 IPX TRK Restriction
Class 7
38-45: 2400 IPX TRK Restriction
Class 8-15
01: 2000 IPS TRK Restriction Class 1
(RCA)
01: 2000 IPS TRK Restriction Class 1
(RCA)
02: 2000 IPS TRK Restriction Class 2
(RCB)
03: 2000 IPS TRK Restriction Class 3
(RCC)
04: 2000 IPS TRK Restriction Class 4
(RCD)
05: 2000 IPS TRK Restriction Class 5
(RCE)
06: 2000 IPS TRK Restriction Class 6
(RCF)
07: 2000 IPS TRK Restriction Class 7
(RCG)
08: 2000 IPS TRK Restriction Class 8
(RCH)
TRUNK-TO-TRUNK RESTRICTION-CCIS
