SWITCH
NAME
SWITCH
NUMBER
SETTING
POSITION
FUNCTION CHECK
SW1(Dip SW)
1
ON
• Common channel signaling data
transmission speed (For Digital Inter-
face)
OFF
2
ON
OFF
3
ON
OFF
4
ON
OFF
5
ON
OFF
6 Not used (Always set to OFF)
7 Not used (Always set to OFF)
8 Not used (Always set to OFF)
Continued on next page
8
7
6
5
4
3
2
1
ON
TRANSMISSION
SPEED
SW
1-1
SW
1-2
SW
1-3
SW
1-4
SW
1-5
48 Kbps NOTE 5 ON ON OFF OFF ON
48 Kbps NOTE 5 ON ON ON OFF ON
56 Kbps ON ON OFF ON ON
64 Kbps ON ON ON ON ON
OFF
OFF
OFF
PN-30CCTA (CCT)
