CHAPTER 5 OPERATION TEST
– 423 – NWA-008853-001 Rev.3.0
97ch5001.fm
Alarm Indications on 30DTI
LED
LED INDICATION FAULT
NORMAL FAULT CAUSE ACTION
RUN Flash
(120 IPM)
On or Off Abnormal operation
of DTI card
Confirm the programming data:
CM05 Y=0/Y=1, CM07 Y=01.
Check to see if the SENSE switch
is set as per the AP number (04-15,
20-31) assigned by CM05 Y=0.
Reset the MB switch
(Down→Up→Down)
If the fault cannot be cleared,
replace the card.
PCM Off On No PCM signals
arrive from the dis-
tant office
Check to see if the line is correctly
connected to the DTI card.
Plug and unplug the DTI card.
Repeat this two or three times.
FRM Off On Frame Alignment
signals from the
distant office can-
not be received
Check the receive line and exter-
nal equipment.
Replace the remote DTI card.
MFRM Off On Multi Frame Align-
ment signals from
the distant office
cannot be received
Check the receive line and exter-
nal equipment.
Replace the remote DTI card.
RMT Off On Frame Alignment
signals cannot be
sent to the remote
PBX
Check the transmission line and
external equipment.
Replace the DTI card.
Continued on next page
1
2
3
4
1
2
1
2
1
2
1
2
LOOPBACK TEST
