CHAPTER 18 SERIAL INTERFACE CHANNEL 1

Figure 18-10. Buffer RAM Operation in 6-Byte Transmission/Reception

(in Basic Transmit/Receive Mode) (2/2)

(b) 4th byte transmission/reception

Receive data 1 (R1)

Receive data 2 (R2)

Receive data 3 (R3)

Transmit data 4 (T4)

Transmit data 5 (T5)

Transmit data 6 (T6)

FADFH

FAC5H

FAC0H

Receive data 4 (R4) SIO1

0 CSIIF1

2 ADTP

–1

Receive data 1 (R1)

Receive data 2 (R2)

Receive data 3 (R3)

Receive data 4 (R4)

Receive data 5 (R5)

Receive data 6 (R6)

FADFH

FAC5H

FAC0H

SIO1

1 CSIIF1

0 ADTP
