ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
Virtual Private Networking Using IPsec Connections 5-31
v1.0, April 2010
To delete one or more VPN polices:
1. Select the check box to the left of the policy that you want to delete, or click the Select All
table button to select all VPN policies.
2. Click the Delete table button.
To enable or disable one ore more VPN policies:
1. Select the check box to the left of the policy that you want to delete, or click the Select All
table button to select all IKE Policies.
2. Click the Enable or Disable table button.
For information about how to add or edit a VPN policy, see the next section, “Manually Adding or
Editing a VPN Policy.”
Manually Adding or Editing a VPN Policy
To manually add a VPN policy:
1. Select VPN > IPSec VPN from the menu. The IPsec VPN submenu tabs display, with the IKE
Policies screen in view (see Figure 5-20 on page 5-22).
2. Click the VPN Policies submenu tab. The VPN Policies screen displays (see Figure 5-22 on
page 5-30).
3. Under the List of VPN Policies table, click the Add table button. The Add New VPN Policy
screen displays (see Figure 5-23 on page 5-32).
Auth The authentication algorithm that is used for the VPN tunnel. This setting must
match the setting on the remote endpoint.
Encr The encryption algorithm that is used for the VPN tunnel. This setting must
match the setting on the remote endpoint.
Note: You cannot delete or edit an IKE policy for which the VPN policy is active. You
first must disable or delete the VPN policy before you can delete or edit the IKE
policy.
Table 5-11. List of VPN Policies Information (continued)
Item Description (or Subfield and Description)
