4.17 File operation
FRA5087
Character string entry : Select a character you want to enter by using the
ITEM
key.
Press the MENU OPEN key to display the
selected character at the entry display portion at the
bottom of the LCD screen and to shift the cursor to
the right by one character at the entry display
portion.
Repeat this operation when you want to enter more
than one character.
Note that you can enter figures 1 - 9 and
SP from the ENTRY key also.
After entering a character string as you need, press
the ENTRY ENTER key to define the character
string.
c) LOAD … To load measurement data and setting conditions (to read in)
[DATA] : To load measurement data
[CONDITION] : To load setting conditions
Select the menu to display a list of files. Press the ITEM
key to select a file you
want to read in. The selected file will be displayed in inverted characters. Press the
function key [LOAD] to load the selected file.
If you want to specify the file name by yourself and load the file, press the OPEN key in the
state where a list of files is displayed. Pick up characters as you want from the TABLE
(character string table) to enter the file name (See “Character string entry” above). Press the
ENTER key to define the file name. And then, press the function key [LOAD] to load
(read in) the data and conditions.
A part of the measurement conditions is added to individual DATA files; it is required,
however, that you load the CONDITION file also so that the FRA5087 is to be set at the
same condition.
d) DELETE … To delete the file
Press the ITEM
key to select a file you want to delete in the list of files displayed.
Press the function key [DELETE] to delete the selected file.
T A B L E
A B C D E F G
H I J K L M N
O P Q R S T U
V W X Y Z . 0
1 2 3 4 5 6 7
8 9 ! # $ % &
< > - @ _ { }
A
