Initialized settings：
Initialized settings are indicated in the table.
Settings related to output on/off, output on/off at power on, arbitrary waveform, setting memory, user units ,
remote control, GPIB address, GPIB delimiter, and USB ID are not initialized.
Initialization table
Key operation Menu Initial settings Remarks
CH 1/CH 2 CH 1(BOTH is off)
CHANNEL MODE INDEP
MODE NORMAL
TYPE BURST
SOURCE EXT (1 ms, at INT) When TYPE=TRIG, GATE,T-GATE
SOURCE(CH2) EXT CH2 (1 ms, at
INT)
When TYPE=TRIG, GATE,T-GATE
DELAY 0.3 µs When TYPE=TRIG
MARK 1.0 When TYPE=BURST, TRIG
SPACE 1.0 When TYPE=BURST
STOP-LEVEL OFF (0%, at ON).
MODE→BURST
OPER-COMMON OFF Both channels MODE=BURST,
TYPE=TRIG, GATE or T-GATE,
same TYPE.
TYPE FREQ
SOURCE EXT (1 ms at INT) When MODE=SINGLE, GATED
SOURCE(CH2) EXT CH2 (1 ms, at
INT)
When MODE=SINGLE, GATED
MODE SINGLE
FUNCTION LIN
TIME 1 s
STOP-LEVEL OFF (0%, at ON). When MODE=GATED
MODE→SWEEP
OPER-COMMON OFF When both channels SWEEP MODE
START 1000 Hz
STOP 10000 Hz
CENTER 5500 Hz
SPAN 9000 Hz
MODE → SWEEP,
TYPE=FREQ
MARKER 5000 Hz
START 0.1Vp-p
STOP 1Vp-p
CENTER 0.55Vp-p
SPAN 0.9Vp-p
MODE → SWEEP,
TYPE=AMPTD
MARKER 0.5Vp-p
Continued next page
