3.3 Basic operation
WF1946B
3-18
Continued from previous page
Key operation Menu Initial settings Remarks
START 0.1V
STOP -0.1V
CENTER 0V
SPAN 0.2V
MODE → SWEEP,
TYPE=OFFSET
MARKER 0V
START −90 deg
STOP 90 deg
CENTER 0 deg
SPAN 180 deg
MODE → SWEEP,
TYPE=PHASE
MARKER 0 deg
START 40%
STOP 60%
CENTER 50%
SPAN 20%
MODE → SWEEP,
TYPE=DUTY
MARKER 50%
TYPE FM
FREQUENCY 100 Hz
FUNCTION
MODE→MODU
OPER-COMMON OFF When both channels MODU MODE
MODE → MODU,
TYPE=FM
DEVIATION 1000 Hz
MODE → MODU,
TYPE=AM
DEPTH 50%
MODE → MODU,
TYPE=OFSM
DEVIATION 0.2V
MODE → MODU,
TYPE=PM
DEVIATION 90 deg
MODE → MODU,
TYPE=PWM
DEVIATION 20%
ENTRY→FREQ 1000 Hz
ENTRY→AMPTD 0.1 Vp-p
ENTRY→OFFSET 0 V
ENTRY→PHASE 0 deg
ENTRY→WIDTH 0.0005 s In case of FUNCTION=
ENTRY→DUTY 50 % In case of FUNCTION=
ENTRY→PERIOD 0.001 s
ENTRY→HIGH 0.05 V
ENTRY→LOW −0.05 V
Continued next page
