4.2 Sweep
4-24 WF1946B
(2) Set sweep TYPE to amplitude (AMPTD)
① Use the
and keys to produce the following display (TYPE flashes).
ＦＲＥＱ ＰＨＡＳＥ ＯＦＦＳＥＴ
4
Ｆ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ
4
② Press the
ENTER
key, then use the and keys to produce the following display
(AMPTD flashes).
ＦＲＥＱ ＡＭＰＴＤ ＯＦＦＳＥＴ
4
Ａ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ
4
③ This completes setting the sweep type to amplitude. Press the
EXIT
key once to release the
setting mode.
(3) Select the sweep FUNCTION
① Use the
and keys to produce the following display (FUNCTION flashes).
ＬＩＮ
Ａ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ
4
② Press the
ENTER
key.
③ Press the
key, then turn the
MODIFY
dial to select .
④ After selecting, press the
EXIT
key once to release the function select mode.
