4.2 Sweep
WF1946B 4-25
(4) Set the START amplitude (START)
① Use the
and keys to produce the following display (START flashes).
ＡＭＰＴＤ ０．１０００ Ｖｐ－ｐ
Ａ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ
4
② Press the
ENTER
key.
③ Set the start amplitude with the key pad or
MODIFY
dial.
For example, set to 1Vp-p.
④ After setting, press the
EXIT
key once to release the start setting mode.
(5) Set the STOP amplitude (STOP)
① Use the
and keys to produce the following display (STOP flashes).
ＡＭＰＴＤ ０．１０００ Ｖｐ－ｐ
Ａ－ＳＷＰ：
3
ＳＴＯＰ ＴＩＭＥ ＣＥＮＴＥＲ ＳＰＡＮ
4
② Press the
ENTER
key.
③ Set the stop amplitude with the key pad or
MODIFY
dial.
For example, set to 2Vp-p.
④ After setting, press the
EXIT
key once to release the stop setting mode.
