DISPLAY AND MENU OPTIONS
Table 9. Smart DC Controller - User Menu Functions
Ref.
No.
User Menu
Display
Setting Options
(Bold = Factory
Settings)
Menu Tasks and Explanations
Associated
DC Controller
Connections
6
BF 2 (ON 2 SEC)
WARN BEFORE OPER
0 = off
1 = on
2 = on
Controls warn-before-operate buzzer
and can be congured three ways:
Set to 0: Buzzer is disabled. Set at 0,
buzzer will still beep when alerts, faults,
errors, or entrapment are detected.
Set to 1: Buzzer beeps for 3 seconds
before gate motion begins and
continues through entire gate travel.
Set to 2: Buzzer beeps for 3 seconds
before gate motion begins and
continues for 2 seconds of gate
travel.
(N/A)
WARNING:
Do NOT cut
wires to buzzer
or unplug it
as operator
will not be in
compliance
with UL 325.
Failure to
comply may
result in serious
injury or death.
7
PE 0 (OFF)
PHOTO EYE ALIGN
0 = off
1 = on
When set to 1, operator serves as an
aide in photo-eye emitter/receiver
alignment. Buzzer chirps once when
emitter and receiver are not aligned.
When emitter and receiver are
aligned, buzzer chirps twice. If they
go out of alignment again, buzzer
will chirp once. Alignment Mode is
reset with a limit input or reset input.
Sensor
Common,
Sensor 1,
Sensor 2,
Sensor 3
8
CL 0
SET CLOCK
0 = Display
1 = Set Clock
To set or adjust minute, hour, day,
month or year, select 1. Once clock
is set, display automatically returns
to 0 setting. Signicant gate events
are logged and stamped with time
and date. This feature is useful to
read historical operation data, which
can be accessed with a computer via
USB or RS232 port or the LG setting
in User Menu. See "Setting the Time
and Date" on page 41.
(N/A)
9
LD 5
LCD CONTRAST
5
0 through 9
Under some extreme high or low
temperature conditions, it may be
necessary to adjust LCD contrast.
Display is adjustable from 0-9 with
a factory default setting of 5.
(N/A)
