DISPLAY AND MENU OPTIONS
Table 10. Smart DC Controller - Installer Menu Functions
Ref.
No.
User Menu
Display
Setting Options
(Bold = Factory
Settings)
Menu Tasks and Explanations
Associated
DC
Controller
Display
Connections
7
FD 0 (OFF)
FACTORY DEFAULTS
0 = custom user
settings
1 = reload factory
default settings
Globally restores all menu
settings back to new operator
status. Select setting 1 to return
operator to factory defaults.
NOTE: If factory defaults are
restored, the UL usage class,
handing, gate weight, and any
other modied menu settings will
need to be reprogrammed.
(N/A)
8
DG 0 (OFF)
DUAL GATE
0 = solo operator
1 = Secondary unit
2 = Primary unit
3 = Sally Port A
4 = Sally Port B
Configures gate operator as a
Primary or as a Secondary in a
dual-gate installation. When you
assign one unit as Primary, you
must congure other as Secondary
through Installer Menu. This menu
is also used to congure a Sally Port
system by setting one operator to
Sally Port A and the other to Sally
Port B.
3-wire
shielded
cable to
DUAL
GATE input
terminals.
Connect Dual
Gate COM
(Gate 1) to
Dual Gate
COM (Gate
2).
Pair wires:
A - A, COM
- COM, and
B - B
9
SG 0 (OFF)
SEQUENCED GATE
0 = solo operator
1 = Loop View #1
2 = Loop View #2
3 = Loop View #3
4 = Loop View #4
Establishes communication after
wiring two or more gate operators
as sequential gates. This SG menu
item only appears if the Dual Gate
menu item (DG) is set to 0 (solo
operator).
NOTE: After selecting SG settings,
consider accessing the User Menu
in each gate operator to address
the Close Timer (CT) setting.
3-wire
shielded
cable to
DUAL
GATE input
terminals
on both
operators.
Pair wires:
A - A, COM
- COM, and
B - B
