The Computer
5-28 Manual # 42-02-1P28 A3
R2L Redundancy 2L bus. Used to monitor the normally closed contact of an additional 2L
relay.
RECALL S1 When active, recalls car to programmed floor. See CONFIG 03 Recall Switches
RECALL S2 When active, recalls car to programmed floor. See CONFIG 03 Recall Switches
RECALL S3 When active, recalls car to programmed floor. See CONFIG 03 Recall Switches
RECALL S4 When active, recalls car to programmed floor. See CONFIG 03 Recall Switches
RESYNC When active, forces jack resynchronization operation
RFV Redundancy Fast Valve - Used to monitor the up/down fast valve relay when the VALVE
TYPE option is set to PILOT RELAYS.
RSV Redundancy Slow Valve - Used to monitor the up/down slow valve relay when the VALVE
TYPE option is set to PILOT RELAYS.
SABBATH IN Sabbath Operation Input
SAF EDGE/SAF
EDGER
Safety Edge. When active, reopens doors
SAF EDGE-C/
SAF EDGER-C
Inverted Safety Edge. When low, reopens doors
SECBRAC_(A-H) Security bracelet inputs used for wandering patient (Floors 1-8)
SECBRAC_OV Security bracelet override
SEC CCEN OV Car Call Security Enable Security Override Input. When active, car call security is disabled
SEC HCEN OV Hall Call Security Enable Security Override Input. When active, hall call security is disabled
SECRTY OV Security Override input. When active, both car and hall call security are disabled.
SLOW INSP Slow Inspection Speed. Slows car to reduced inspection speed when active
STD Step down vane or magnet for down direction of travel. Also used for floor encoding.
STU Step up vane or magnet for up direction of travel. Also used for floor encoding.
ULMF/ULMR Up level marker. Used to locate floor for preopening and for final approach. Inner leveling
zone is set by ULM and DZ
Table 5.4 Spare Outputs
Output Description
NOT USED Input is not used
APS DONE Auxiliary Power Supply complete. HAPS asserts this output when return is complete
ARROW DN Turns ON when preferred direction of travel is below the car's present location.
ARROW UP Turns ON when preferred direction of travel is above the car's present location.
ARROW DN 2 Turns ON when preferred direction of travel is below the car's present location.
Will turn OFF during certain modes of operation and/or conditions per the configured
options for disabling the spare and/or the dedicated UIO PI outputs (Inspection, Fire, Med-
ical, etc.)
ARROW UP 2 Turns ON when preferred direction of travel is above the car's present location.
Will turn OFF during certain modes of operation and/or conditions per the configured
options for disabling the spare and/or the dedicated UIO PI outputs (Inspection, Fire, Med-
ical, etc.)
ATS ON Attendant Service Light
ATS BUZZER Attendant Service Buzzer
ATS HCBABOVE Attendant hall call assigned above the car
ATS HCBELOW Attendant hall call assigned below the car
Table 5.3 Spare Inputs
Input Description
