The Computer
5-30 Manual # 42-02-1P28 A3
DISAUTOCLSR Disable Auto Close Rear. Used on freight doors that are not controlled by MCE, this output
comes when front door auto closing is not allowed (Fire recall complete, Fire Phase II,
IND, ATS, Door Hold...).
DISHALBTNSF Disable Hall Door Buttons Front. Used on freight doors that are not controlled by MCE, this
output comes on when all front hall door buttons (DOB, DCB, DHOLD…) need to be dis-
abled (Fire Phase II, IND, ATS...).
DISHALBTNSR Disable Hall Door Buttons Rear. Used on freight doors that are not controlled by MCE, this
output comes on when all front hall door buttons (DOB, DCB, DHOLD…) need to be dis-
abled (Fire Phase II, IND, ATS...).
DLEFT OPENF Door Left Open Bell Front output. Used for non-automatic doors. It comes on if the front
doors are open, while a front/rear hall call button is pressed.
DLEFT OPENR Door Left Open Bell Rear output. Used for non-automatic doors. It comes on if the rear
doors are open, while a front/rear hall call button is pressed.
DOF/DOFR Turns ON to open the doors. Door Open Function
DOOR CAM F Door Cam Front output. Used on jobs with a retiring cam mechanism to lock the hoistway
doors. It comes on when there is a demand to move and both front/rear car gates are
closed. This output shall not be ON if the car is stopped in between floors.
DOOR CAM R Door Cam Rear output. Used on jobs with a retiring cam mechanism to lock the hoistway
doors. It comes on when there is a demand to move and both front/rear car gates are
closed. This output shall not be ON if the car is stopped in between floors.
DOOR ENAB F Door Enable Front. Used on freight doors that are not controlled by MCE, this output
comes on to enable the front door operation. It is turned off during whenever door opera-
tion is disabled (Inspection, Test, door stop, in-car stop switch…).
DOOR ENAB R Door Enable Rear. Used on freight doors that are not controlled by MCE, this output comes
on to enable the front door operation. It is turned off during whenever door operation is
disabled (Inspection, Test, door stop, in-car stop switch…).
EF GONG Egress floor arrival gong
EMSC BUZZR Emergency Medical Service car buzzer output
EMSC LIGHT Emergency Medical Service car light output
EMSH LIGHT Emergency Medical Service hall light output
EP CAR DONE Emergency power recall done output. This output comes ON 4 sec after the doors are fully
open to allow for releveling.
EP LIGHT Emergency power light. Flashes when car is selected to recall on emergency power. Solid
when car is selected to run.
EP LOBBY Intended to drive a light at the designated emergency power return floor after the car is at
the floor with doors open on emergency power
EP ON Emergency power ON output
EP SELECT Emergency power car selected to recall or run output
EP1 ON Emergency power lowering phase output
EP1 RECALL Emergency power car selected to recall output
EP2 ON Emergency power Phase 2 run output active
EP2 RUN Emergency power car selected to run output
EPOVL R. FAIL Emergency Power Overlay Recall Fail output. Activated by the car that is commanded to
recall if it fails to complete the recall within the user defined time (needed for EP 2008 and
later).
EPOVL INIT R Emergency Power Overlay re-Initiate Recall output. Activated by the car when emergency
power recall needs to be re-initiated. Used when the car has recalled to a floor that is no
longer safe due to Flood of Fire (needed of EP 2008 and later).
Table 5.4 Spare Outputs
Output Description
